PRODUCT MODEL YEAR |
2010 |
PRODUCT OPTIONS |
S, M, L |
Frame |
New Mongoose FreeDrive DH 210mm travel and 150mm Maxle drops
Rear Shock: Fox Van R rebound and preload adjust, 241x76 mm w/ 19x8 mm hardware
|
Forks |
Rock Shox Boxxer Race 200 mm travel, rebound, compression and preload adjust, 20 mm Maxle thru axle
|
Rear Derailleur |
SRAM X.9 medium cage
|
Shifters |
SRAM X.7 9 speed
|
Chainset |
Truvativ Hussefelt with cromoly pedal inserts1.0 36T ring
|
Bottom Bracket |
Truvativ Howitzer TM (83 mm shell)
|
Chain |
KMC X9 w/ Missing Link connector
|
Freewheel / Cassette |
SRAM PG-950 Cassette 11-26
|
Headset |
FSA Orbit Z 1.5 Flush Fit, reduces 1.5 head tube to 1 1/8" fork
|
Stem |
FUNN RSX 25.4x45 mm direct attach for Boxxer, CNC alloy
|
Handlebars |
Funn Full Bore triple butted AL7075 riser, 25.4x50x710 mm
|
Front Brake |
Avid Code 5 four piston caliper, 203 mm rotor |
Rear Brake |
Avid Code 5 four piston caliper, 185 mm rear rotor
|
Brake Levers |
Avid Elixir
|
Rims |
SUN MTX-31 32 hole
|
Front Hub |
Formula sealed bearing 20mm thru axle
|
Rear Hub |
Formula sealed bearing 150x12 thru axle cassette
|
Spokes |
DT Champion 14G stainless
|
Tyres |
Kenda Excavator DH w/ Stick-E rubber 26X2.5
|
Saddle |
Custom Mongoose SDG Bel Air I-Beam
|
Seatpost |
SDG I-Beam 2014 alloy, 31.6x250
Seat Clamp: Alloy w/ QR
|
Pedals |
Funn melt forged with 3M mini panel and replaceable pins
|
Grips |
Mongoose Lock on
|
Miscellaneous |
E.13 LG1alloy back plate ISCG05 chainguide w/ Taco bash guard, Rock Shox Maxle
|
